OMAX 40X-1600X Advanced Trinocular Phase Contrast Microscope with Sliding Phase Contrast Kit description
User reviews for OMAX 40X-1600X Advanced Trinocular Phase Contrast Microscope with Sliding Phase Contrast Kit -
OMAX 40X-1600X Advanced Trinocular Phase Contrast Microscope with Sliding Phase Contrast Kit features
- Total magnification for brightfield: 40X-64X-100X-160X-400X-640X-1000X-1600X; Total magnification for phase contrast: 100X-160X-400X-640X; Eyepieces: widefield WF10X/18 and P16X; Brightfield objectives: achromatic DIN 4X, 10X, 40X (S), 100X (S, Oil); PLAN phase contrast objectives (in phase contrast kit): 10X, 40X (S)
- Viewing head: 45 degrees inclined 360 degrees swiveling binocular; Interpupillary distance: sliding adjustable 2-3/16inch ~ 2-15/16inch (55~75mm); Diopter: adjustable on both eyepiece tubes; Nosepiece: revolving quadruple; Stage: mechanical stain-resistant double layer size 5-1/2inch x 5-1/2inch (140mm x 140mm), translation range: 3inch x 2inch (75mm x 50mm); Focus: coaxial coarse and fine focus knobs on both sides, rack and pinion adjustment, with tension control
- Focusing knob can be locked for observation and transportation; Condenser and diaphragm: NA1.25 Abbe condenser with iris diaphragm and filter holder, rack and pinion adjustment; Substage phase contrast condenser: NA1.25 (37mm mounting size) with three-setting plate for 10X, 40X, and brightfield (no phase) annular rings, each can be centered individually
- Black palm rest on the base; Illumination: transmitted (lower), 6V 20W halogen light, variable intensity; Metal framework; Power supply: 100V~240V 50/60Hz worldwide range (US and Canada power plug)
- 5-year warranty against manufacturing defects
OMAX 40X-1600X Advanced Trinocular Phase Contrast Microscope with Sliding Phase Contrast Kit best price
